| 参数 | Specifications | 技术指标/Technique |
| 额定容量 | Capacity | 0.1,0.2,0.3,0.5,1~5Nm |
| 输出灵敏度 | Rated output | 1.0~1.5mV/V |
| 零点输出 | Zero balance | ±2%F.S. |
| 非线性 | Non-linearity | ±0.1,0.3%F.S. |
| 滞后 | Hysteresis | ≤±0.05%F.S. |
| 重复性 | Repeatability | ≤±0.05%F.S. |
| 蠕变(30min) | Creep(30min) | ≤±0.05%F.S. |
| 温度灵敏度漂移 | Temp.effect on output | 0.3%F.S./10℃ |
| 零点温度漂移 | Temp.effect on zero | 0.3%F.S./10℃ |
| 输入电阻 | Inputimpedance | 700±10Ω |
| 输出电阻 | Output impedance | 350±10Ω |
| 绝缘电阻 | Insulation | ≥5000MΩ/100VDC |
| 激励电压1 | Recommended excitation1 | 10~15VDC |
| 最大激励电压 | MAximum Excitation | 20V |
| 温度补偿范国 | Compensated temp range | -10~60℃ |
| 工作温度范围 | Operation temp range | -35~65℃ |
| 安全超载 | Safe overload | 150%F.S. |
| 极限超载 | Ultimate overload | 150%F.S. |
| 电缆线尺寸 | Cable size | φ5.2×3m |
| 防护等级 | Capacity | IP66 |
