| 参数 | Specifications | 技术指标/Technique |
| 额定容量 | Capacity | 50~500N |
| 精度等级 | Accuracy class | 0.1%F.S. |
| 额定输出 | Rated output | 2.0±0.2mV/V |
| 零点输出 | Zero balance | ±2% F.S. |
| 非线性 | Non-linearity | ±0.05%F.S. |
| 滞后 | Hysteresis | ±0.05%F.S. |
| 重复性 | Repeatability | ±0.05%F.S. |
| 蠕变(30min) | Creep(30min) | ±0.05%F.S. |
| 温度灵敏度漂移 | Temp.effect on output | ±0.1%F.S./10℃ |
| 零点温度漂移 | Temp.effect on zero | ±0.1%F.S./10℃ |
| 输入电阻 | Input impedance | 350±10Ω |
| 输出电阻 | Output impedance | 350±5Ω |
| 绝缘电阻 | Insulation | ≥5000MΩ/50VDC |
| 激励电压 | Excitation Voltage | 5~10V |
| 最大激励电压 | Maximum excitation Voltage | 15V |
| 温度补偿范围 | Compensated temp range | -10~40℃ |
| 工作温度范围 | Operation temp range | -20~60℃ |
| 安全超载 | Safe overload | 120%F.S. |
| 极限超载 | Ultimate overload | 150%F.S. |
| 电缆线尺寸 | Cable size | Ф5.3×3m |
| 防护等级 | IP Class | IP66 |
