技术参数
| 参数 | Specifications | 技术指标/Technique |
| 输出灵敏度 | Rated output | 2.0+0.1mV/V |
| 零点输出 | Zero balance | ±0.05%F.S. |
| 非线性 | Non-linearity | 0.015%F.S. |
| 滞后 | Hysteresis | 0.015%F.S |
| 重复性 | Repeatability | 0.015%F.S. |
| 蠕变(30min) | Creep(30min) | 0.0166%F.S. |
| 温度灵敏度漂移 | Temp.effect on output | 0.02%F.S./10℃ |
| 零点温度漂移 | Temp.effect on zero | 0.03%F.S./10℃ |
| 输入电阻 | Input impedance | 405±20Ω |
| 输出电阻 | Output impedance | 350+10Ω |
| 绝缘电阻 | Insulation | ≥5000MΩ/100VDC |
| 激励电压 | Excitation Voltage | 5~15V |
| 最大激励电压 | Maximum excitation Voltage | 15V |
| 温度补偿范围 | Compensated temp range | -10~40℃ |
| 工作温度范围 | Operation temp range | -10~50℃ |
| 安全超载 | Safe overload | 150%F.S. |
| 极限超载 | Ultimate overload | 200%F.S. |
| 电缆线尺寸 | Cable size | 4-Ф1x100mm |
| 材料 | Material | Stainless steel(不锈钢) |
| 防护等级 | IP Class | IP68 |
| 最大秤盘尺寸 | Max.platform size | 50mmx50mm |
